Huawei CloudLink Box 310/610 Ultra HD Video Conferencing Terminal
- Classification:Huawei video conferencing terminal
- Release time:2025-11-24
- Page views:0
Huawei's new generation of ultra-high-definition video conferencing terminals, featuring independently developed core technologies, HarmonyOS, and a high-performance computing hardware platform architecture, boasts H.265 4K dual-stream audio and video media processing capabilities, providing a superior conferencing experience. It also offers rich audio and video content.The frequency interface can be adapted to various types of cameras and display devices to meet the integration needs of various types of conference rooms.

1. High security and high reliability
• Powered by HarmonyOS, with independently developed core technologies, and adopting a new generation of high-performance hardware platform architecture, delivering powerful performance;
• Supports national cryptographic conferences, signaling and media protocols are certified and encrypted using national cryptographic algorithms, ensuring encrypted transmission and preventing data leakage even in case of loss;
• One device, one certificate, to prevent terminal hijacking and counterfeiting;
2. Professional Ultra HD
• H.265 hardware encoding and decoding + Huawei's proprietary VME technology effectively remove noise from moving images, achieving 4K ultra-high-definition video with delicate colors and an exquisite immersive experience.
• Supports H.265 4K multi-stream conferencing, allowing the terminal to simultaneously encode and decode multiple video streams of different formats, enabling flexible local adjustment of multi-screen layout and selection of any meeting room;
• Excellent network adaptability, with 30% packet loss resistance for video;
• Utilizing ultra-low latency 4K frame rate technology, the video display can reach up to 4K 60 frames per second, resulting in smoother and more fluid video effects;
3. Flexible expansion
• It has rich audio and video interfaces, supports flexible conference room integration and multi-screen expansion, and comes with Huawei CloudLink Camera 200 and CloudLink Mic 500 microphones, which can quickly complete the deployment of conference rooms;
• HT-RX interface, combining video transmission, camera control and power supply, supporting long-distance connection up to 100 meters;
Technical parameters
| model | Box 310 | Box 310-S | Box 310-C | Box 310-K | |||
| Multimedia Framework Protocol | ITU-T H.323、IETF SIP | ||||||
| Video codec protocols | H.265、H.265 SVC、H.264 HP、H.264 BP、H.264 SVC、H.263、H.263+ | ||||||
| Audio codec protocols* | OPUS、AAC-LD、G.729A、G.722、G.722.1C、G.719、G.711U、G.711A | ||||||
| Video features* | Active image resolution: 4K 30fps,1080p 60fps,1080p 30fps,720p 60fps,720p 30fps Shuangliu Events: 4K30 + 4K30 1080P60 + 1080P60 1080P30 + 1080P30 | Active image resolution: 4K 30fps,1080p 60fps,1080p 30fps,720p 60fps,720p 30fps Shuangliu Events: 4K30 + 4K30 1080P60 + 1080P60 1080P30 + 1080P30 | Active image resolution: 1080p 60fps,1080p 30fps,720p 60fps,720p 30fps Shuangliu Events: 1080P60 + 1080P60 1080P30 + 1080P30 | Active image resolution: 4K 30fps,1080p 60fps,1080p 30fps,720p 60fps,720p 30fps Shuangliu Events: 4K30 + 4K30 1080P60 + 1080P60 1080P30 + 1080P30 | |||
| bandwidth | IP: 64kbps~8Mbps | IP: 64kbps~8Mbps | IP: 64kbps~4Mbps | IP: 64kbps~8Mbps | |||
| Video input interface | 1 x HT-RX 2 x HDMI | 1 x HT-RX 2 x HDMI | 1 x HT-RX 2 x HDMI | 1 x HT-RX 2 x HDMI | |||
| Video output interface | 2 × HDMI | 2 × HDMI | 2 × HDMI | 2 × HDMI | |||
| Audio input interface | 1 × HD-AI (Level 2) 1 × Canon Head 2 × HDMI (audio input) 2 × RCA | 1 × HD-AI (Level 2) 1 × Canon Head 2 × HDMI (audio input) 2 × RCA | 1 × HD-AI (Level 2) 1 × Canon Head 2 × HDMI (audio input) 2 × RCA | 1 × HD-AI (Level 2) 1 × Canon Head 2 × HDMI (audio input) 2 × RCA | |||
| Audio output interface | 4 × RCA 2 × HDMI (audio output) | 4 × RCA 2 × HDMI (audio output) | 4 × RCA 2 × HDMI (audio output) | 4 × RCA 2 × HDMI (audio output) | |||
| Other interfaces* | 1 x USB 2.0 A port 1 x USB 3.0 A port 2×10/100/1000M LAN 1×PoE Ethernet port (Touch) 2×RJ45 serial ports 1×WIFI (built-in) | 1 x USB 2.0 A port 1 x USB 3.0 A port 2×10/100/1000M LAN 1×PoE Ethernet port (Touch) 2×RJ45 serial ports | 1 x USB 2.0 A port 1 x USB 3.0 A port 2×10/100/1000M LAN 1×PoE Ethernet port (Touch) 2×RJ45 serial ports 1×WIFI (built-in) | 1 x USB 2.0 A port 1 x USB 3.0 A port 2×10/100/1000M LAN 1×PoE Ethernet port (Touch) 2×RJ45 serial ports 1×WIFI (built-in) | |||
*: Please contact your local Huawei sales representative for more details.
